Century Centurion 1081 Series 1.5 HP, 56Y Frame Motor B2854V1

Item #: B2854V1
$279.95

This item is IN STOCK

This item is TEMPORARILY OUT OF STOCK

Usually Ships Within 1 Business Day

Expedited Shipping NOT Available Not Available Outside Contiguous US

This item is IN STOCK

This item is TEMPORARILY OUT OF STOCK

Usually Ships Within 1 Business Day

Expedited Shipping NOT Available Not Available Outside Contiguous US
Notify me when restocked

Item Details

Century Centurion 1081 Series Motor B2854V1

The Centurion line of pool motors combine the proven performance of the Century Centurion 56 frame platform with the next generation of features for increased reliability, added performance, premium efficiency, and serviceability.

This is the first full line of upgraded pool motors... the "best of the best" from Century.

Features:

  • Centurion "1081" Series Energy Efficient Motor
  • No-adjust start switch that is rated for over one million cycles for motor longevity
  • Unique electrical design with a unique, advanced cooling system that helps extend the life of the motor
  • Heavy duty shaft made from 303 grade stainless steel helps prevent corrosion
  • EZ wrench access that doesn't require the removal of the wiring compartment canopy
  • Angled terminal makes wiring connections a breeze
  • Patented voltage change dial for easy voltage selection
  • Patented bonding lug for easy ground connections
  • Patented bearing lock clip for for assured bearing retention
  • All motors are rated 115/208-230 +/-10% volts to handle voltage variations throughout the US and Canada
  • Double sealed bearings and, on shaft end, an integrated Patented SmithSealTM bearing protector to resist water damage
  • Rugged motor enclosure system for enhanced durability and premium protection against corrosion
  • A full class F insulation system and 50° C ambient capability for increased motor life over class B insulation systems
Specifications:
  • Horsepower: 1-1/2
  • Service Factor: 1.10
  • Total Horsepower: 1.65
  • Volts: 115/230
  • Amps: 8.0/16.0
  • RPM: 3450
  • Frame: 56Y
  • Flange: Square Flange
  • Shaft: Threaded
  • Series: Centurion Energy Efficient
  • Up-Rated

Note:

  • Not available for sale in the state of California
Century B2854V1

Customer Reviews

Based on 2 reviews
100%
(2)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
T
TxWalker
Perfect Replacement

The motor on my 14 year old Stealth pump died. I found the upgraded version of the OEM replacement at Sunplay, at the lowest price (from a reputable vendor). It arrived in short order, packed in a very protective package. I have 2 other motors, and a pump, that are destined to out. Now, I have my Go-To store for pool equipment! I’d give them 6 stars if possible.

K
Kevin S
Better then original motor

So much room in the back for electrical connections. Built in cooling fans move so much air out of the back keeping the motor fairly cool. Great motor. If your replacing with jandy flopro, the four 1", 3/8 bolt don't come with the backplate or the motor so you'll need to reuse or pickup at local hardware store. Other than that, I like it more than the original.
