Del Ozone AOP 40 Ozonator

Del Ozone AOP 40 Ozonator

The Del AOP 40 next generation of AOP is designed to give you everything you need in a high-powered advanced sanitizer.

DEL AOP is dramatically more powerful than chlorine and other sanitizers, and even more powerful than ozone alone. CMP has the only residential AOP ozone/UV systems classified by NSF as a supplemental sanitizer.

Next Gen AOP systems are not only powerful: they are designed for easy installation, simple service and smart feedback.

Features:

• UV and Ozone Sanitizing System
• Two sanitizers work together to create powerful Hydroxyl Radicals
• Hydroxyl radicals destroy certain viruses & bacteria . . . Plus other organic and inorganic pool water contaminants.
• Chloramines cause irritation and that familiar “pool smell.” AOP destroys sweat and other nasties that form chloramines in the water.
• Contaminants are destroyed and filtration is enhanced resulting in pure, polished, crystal-clear water.
• Powerful oxidation reduces the amount of chlorine needed to maintain a safe residual in the pool, saving you time and money.
• Full flow generates hydroxyls in the primary pool circulation
• Sensors actively monitor UV-C and ozone sub-systems

• Single cabinet serviceable design

• Easy-access wiring path and terminal block
• APG2 ozone cells: higher output corona discharge, superior heat performance, durable design
• High flow UV-C chamber
• Variable speed pump compatible
• Built-in drain for winterization

Technical Specifications:

• Universal 110/240 Voltage
• Certified sanitization flow rates
• Quarter-turn cam lock door access
• 2" union inlet/outlet connections
• Custom-engineered venturi
• Topside UV-C lamp access
• Integrated flow switch
• Ozone Output of 500mg/hr
• UV Output of 254nm
• Max water flow rate of 40 gallons per minute
• Certifications: NSF/ANSI Standard 50 Supplemental Sanitizer, cUL Listed, UL Listed

Dimensions:

• 12-1/2" Wide x 13-3/8" Depth x 24-1/4" Height

The Science of AOP

• When germicidal UV light (UV-C) and ozone react the result is the production of hydroxyl radicals. This reaction is known as Advanced Oxidation Process, or AOP.
• Hydroxyl radicals (•OH) are the most powerful oxidation agents available, quickly destroying bacteria, viruses, pathogens and other contaminants that occur in water.

Del Ozone 53000-040-000
